The compact wing foiling machine!

Smooth, passive take-offs and effortless touchdown recovery

Our X-Winger boards feature many shape details which make them versatile and agile with a great and smooth overall handling. They are longer and narrower compared to their predecessors. Most importantly they are much more efficient and superior in all aspects supporting the performance of the foil.

The long, narrow hull and the subtle nose rocker provide a good glide for a quick acceleration and a smooth, passive take-off into a flight mode. The clearly defined rail tuck line helps in transferring the lift created by the bottom surface into a crisp water release and an effortless take-off. These shape features work together improving additional characteristics:
On occasional touchdowns the board bounces off the water surface gently and smoothly without losing speed.

Also helping on touchdowns is the pulled-in nose outline that at the same time reduces the swing weight and improves the airflow. Despite the low volume of the pulled-in nose outline, ther is enough thickness in this area. Still, the narrow nose results in a light feel and a agile ride.

The slightly concave standing area provides a more direct feel over the foil.

Another features is the high tail rocker. Once in the air, this additional bottom curve lifts the nose resulting in a better flight position of the board. This creates more clearance when flying so you can push harder on the foil when going upwind without a concern that the board might catch some chop. On top of that it creates more pop for jumps and provides a more comfortable stance.

The X-Wingers also feature unique tail cut-outs. They reduce the wetted surface in the tail area allowing for an efficient take-off as well as a quick recovery from a touch-down. You also can rail the board up hard during turns without the tail catching.

Technical details:
The boards feature long track boxes providing a big tuning range for the foil. The tracks are embedded in high-density blocks running all the way from deck to bottom and creating an extremely stable construction.
Additionally, the PRO boards come with full high density PVC sandwich, deck and bottom offering an unmatched ratio of stiffness and low weight in connection with the Innegra rail reinforcement.

IPR

88
Length (cm)(in): 1535'0"
Width (cm)(in): 6425"
Volume (l): 88
Weight (kg)(lbs): 7,3* 16.1"*
+/- 10%*estimated
Thickness (cm)(in): 12,24.8"
Fin box: 2x Long track box
Windsurf Mast Plug: No
Colors*: 2955 C

433 C

312 C

429 C

99
Length (cm)(in): 1585'2"
Width (cm)(in): 6626"
Volume (l): 99
Weight (kg)(lbs): 7,6* 16.8*
+/- 10%*estimated
Thickness (cm)(in): 12,54.9"
Fin box: 2x Long track box
Windsurf Mast Plug: No
Colors*: 2955 C

433 C

312 C

429 C

111
Length (cm)(in): 1715'7"
Width (cm)(in): 6927"
Volume (l): 111
Weight (kg)(lbs): 8,2* 18.1*
+/- 10%*estimated
Thickness (cm)(in): 12,54.9"
Fin box: 2x Long track box
Windsurf Mast Plug: No
Colors*: 2955 C

433 C

312 C

429 C

122
Length (cm)(in): 1866'1"
Width (cm)(in): 7128"
Volume (l): 122
Weight (kg)(lbs): 8,7* 19.2*
+/- 10%*estimated
Thickness (cm)(in): 12,54.9"
Fin box: 2x Long track box
Windsurf Mast Plug: No
Colors*: 2955 C

433 C

312 C

429 C

133
Length (cm)(in): 1916'3"
Width (cm)(in): 7429"
Volume (l): 133
Weight (kg)(lbs): 9,3* 20.5*
+/- 10%*estimated
Thickness (cm)(in): 12,54.9"
Fin box: 2x Long track box
Windsurf Mast Plug: No
Colors*: 2955 C

433 C

312 C

429 C

144
Length (cm)(in): 1986'6"
Width (cm)(in): 7630"
Volume (l): 144
Weight (kg)(lbs): 9,5* 20.9*
+/- 10%*estimated
Thickness (cm)(in): 12,75.0"
Fin box: 2x Long track box
Windsurf Mast Plug: No
Colors*: 2955 C

433 C

312 C

429 C

*Colors are specified in "Pantone Coated" numbers

Tech Features

Teamrider Talk

An incredible board!

Vinnicius Martins

The X-Winger is an incredible board that provides an exceptional foil sensation, feeling remarkably compact even in larger sizes. Its volume distribution is impeccably balanced, facilitating swift and effortless foiling even in light and erratic winds! The boards boast remarkable ease of use, delivering exceptional speed and responsiveness, making them an ideal complement to the NeilPryde Glide HP foils. They are an outstanding choice for riders of all skill levels!

Foiling Recommendation

2x US track boxes

Surf plate adapter for Glide Surf and Glide Wind Foils. Two mast track boxes allow individual trimming and evenly distribute the pressure.

Glide Surf HP

Wing / SUP / Surf / Tow
Interchangeable head
(Deep Tuttle Box / Powerbox / Surf Plate)

Mast: 70 cm

GLIDE SURF creates a playground for building new surfing sensations. With a stable and fast take off no matter the surf conditions, the GLIDE SURF delivers superior gliding and controlled speed to ride waves as far as they can flow. On the wave, the Glide Surf allows you to fly through the sections and progress from straight riding to progressive foil-turns. Your imagination is now the only limitation to how you will use the waves and how far you will fly.

Pump from one wave to the next – see how long you can fly!

More Info

Glide Swift Carbon

Wing / SUP / Windsurf / Tow
Fixed Head ( Surf Plate)

Mast: 85 cm

The most performant foil for small(freeride) windsurf and especially wing boards: its high aspect wings provide little drag and resistance resulting in great performance. Its speed provides the ideal power for high jumps. It is easy to control and offers a easy take-off. The term describing it best is efficiency!
In winging, its placements at the top GWA events demonstrate that it match the most specialized foils out there but it is much easier to use. It not only impresses in racing, but also earns points in pump sections, waves, and freestyle.
In windsurfing, the Glide Swift won Yentel Caers the first ever foil-style competition on the FPT tour.

Wing Recommendation

Neilpryde FLY II

The 2024 FLY II is an evolutionary advance of the original that features new materials, even more advanced 3D flying shapes, and a host of details that increase performance and make the user experience even better.
